Product Description:
Product overview
① The series has compact design, small host width and good passability. Use variable amplitude working arm. Ensures a strong load carrying capacity in a smaller width.
② The width of the main machine is the smallest in all the sliding machine products. To meet special operational requirements.
③ The product uses imported European and American hydraulic parts. Sensitive control, rapid response, is the best choice for small space operations.
| Operating load (kg) | 300 |
| Maximum driving speed: (high speed) | 8 |
| Minimum travel speed: (low speed) | 4 |
| Tire(track) model | 18*8.5-8 |
| Engine brand: | Briggs&Stratton |
| Rated power (HP) | 13.5HP |
| Fuel tank capacity (L) | 20 |
| Machine net weight: (kg) | 800 |
| Working weight: | 1200KG |
| Bucket capacity (m3) | 0.15 |
| Overall operating height (mm) | 2750 |
| Height to bucket hinge pin (mm) | 2200 |
| Overall length ithout bucket(mm) | 2180 |
| overall length with bucket(mm) | 2680 |
| Dumping angle at maximum height(°) | 38 |
| Dumping height(mm) | 1770 |
| Dumping reach(mm) | 200 |
| Wheelbase(mm) | 950 |
| Ground clearance(mm) | 140 |
| Big arm width: (mm) | 340 |
| Width (mm) | 960 |
| Bucket width (mm) | 1000 |
Features:
- Product Name: Mini Skid Steer Loader
- Machine net weight (kg): 800
- Maximum driving speed (high speed): 8
- Dumping angle at maximum height (°): 38
- Rated power (HP): 13.5HP
- Fuel tank capacity (L): 20
Technical Parameters:
| Crawler Skid Steer Loader | Mini Skid Steer Loader |
| Overall length with bucket(mm) | 2680 |
| Overall operating height (mm) | 2750 |
| Operating load (kg) | 300 |
| Rated power (HP) | 13.5HP |
| Maximum driving speed: (high speed) | 8 |
| Overall length without bucket(mm) | 2180 |
| Working weight | 1200KG |
| Machine net weight (kg) | 800 |
| Minimum travel speed: (low speed) | 4 |
| Height to bucket hinge pin (mm) | 2200 |
Applications:
Thanks to its small size and maneuverability, the HIGHTOP Mini Skid Steer Loader is ideal for working in tight spaces where larger machines can't go. Its powerful engine and hydraulic system allow it to handle heavy loads with ease, making it a great choice for lifting and moving materials on job sites of all kinds.
Whether you're looking to clear land, dig trenches, or move heavy loads, the HIGHTOP Mini Skid Steer Loader has you covered. Its compact design and easy-to-use controls make it a great choice for a variety of applications, including:
- Construction sites
- Landscaping projects
- Agricultural work
- Warehouse and factory operations
- And more!
With its CE and EPA certifications, you can trust the HIGHTOP Mini Skid Steer Loader to meet the highest standards of safety and environmental responsibility. And with a minimum order quantity of just 1 set, it's easy to get started with this versatile machine today.
So why wait? Whether you're a contractor, landscaper, or farmer, the HIGHTOP Mini Skid Steer Loader is the perfect choice for your next job. Contact us today to learn more about pricing, delivery, and other details!
Brand Name: HIGHTOP
Model Number: HTHY800-Y
Place of Origin: Shandong China
Certification: CE,EPA,
Minimum Order Quantity: 1set
Price: Negotiation
Packaging Details: Wooden case
Delivery Time: 5-14 work days
Payment Terms: Western Union, MoneyGram, T/T, D/A, D/P, L/C
Supply Ability: 100 set per month
Overall length with bucket(mm): 2680
Machine net weight: (kg): 800
Overall length ithout bucket(mm): 2180
Bucket capacity (m3): 0.15
Operating load (kg): 300
Customization:
The Skid Steer Loader is packaged in a wooden case and can be delivered within 5-14 work days. Payment terms accepted include Western Union, MoneyGram, T/T, D/A, D/P, and L/C. The supply ability is 100 sets per month.
The Skid Steer Loader has a working weight of 1200KG and a maximum driving speed of 8 (high speed). It has a rated power of 13.5HP and an overall length without bucket of 2180mm. With the bucket, the overall length is 2680mm.
Customization services are available for the Mini Skid Steer Loader product. Contact HIGHTOP for more information.
Support and Services:
Our Mini Skid Steer Loader product comes with a comprehensive technical support and service package to ensure optimal performance and minimal downtime. Our team of experienced technicians is available to assist with any technical issues or questions you may have regarding the product, and we offer regular maintenance and repair services to keep your loader in top condition. Our services include:
- On-site technical support
- Remote technical support
- Regular maintenance and inspection services
- Repair services
- Parts replacement
- Training and education for operators and maintenance staff
We are committed to providing excellent service to our customers and ensuring the long-term success of our products. Contact us for more information on our technical support and service offerings.
Packing and Shipping:
Product Packaging:
- The Mini Skid Steer Loader will be securely packaged in a wooden crate.
- The crate will be sealed with metal strapping to prevent any movement or damage during shipping.
- The package will also include a user manual and any necessary accessories.
Shipping:
- The Mini Skid Steer Loader will be shipped via a reliable and reputable carrier.
- Shipping costs will be calculated based on the destination and weight of the package.
- The estimated delivery time will be communicated to the customer upon purchase.
- The customer will receive a tracking number to track the package during transit.
